Unit of Measure

Body Material

 N/A 303 SS

Ball Material

 N/A 440C SS

Maximum Operating Pressure

 N/A 1000 psig

Maximum Temperature

 N/A 300 ºF

CV - Free Flow

 N/A 0.009

Connection A

 N/A 6/32 UNC Threaded Insert

Seat Leakage

 N/A 20 sccm (max) air flow at 25 psig

Nose Diameter

 N/A 0.090 in

Thread Size

 N/A 6-32

Internal Hex (Width Across Flats)

 N/A 1/16 in

Total Length

 N/A 0.310 in

Thread Length

 N/A 0.236 in

Features

 N/A
  • All metal construction option
  • Long life operation
  • Low cost
